Barcode Scanner Wireless 2D Barcode Reader TH22
Barcode Scanner Wireless 2D Barcode Reader TH22
Couldn't load pickup availability
TH22 Wireless 2D Barcode Reader with Dongle
250m Ultra-Long Range | Multi-Language Output | Fast, Hands-Free Scanning
Product Overview
The TH22 Barcode Scanner Wireless is a rugged, high-speed barcode reader built for businesses that need long-range connectivity, device compatibility, and reliable omnidirectional scanning in one powerful solution.
With a working range of up to 250 meters in open environments, this scanner pairs effortlessly with PCs and tablets via a dongle, ensuring smooth and stable wireless communication.
TH22 Wireless 2D Barcode Reader Equipped with a super large field of view, support for multiple languages, and the ability to scan 1D, 2D, Postal barcodes, and OCR data, the TH22 is ready to take on retail, warehouse, logistics, and healthcare scanning demands.
⭐ Key Features
📶 250m Ultra-Long Wireless Range
- Seamless wireless connection via USB dongle or charging base
- 250-meter communication range in open space, ideal for large warehouses and retail stores
- Quick-connect feature: Scan the barcode on the dongle to auto-pair with PC instantly
🔁 Omnidirectional, High-Speed Scanning
- Reads 1D, 2D, and postal barcodes as well as OCR characters
- Fast scanning from any angle—even from smartphone screens or low-quality labels
🌍 Multi-Language Barcode Data Transfer
- Supports international barcode message output
- Perfect for global operations with localized data input
🧼 Disinfectant-Ready & Rugged Housing
- IP42-rated housing resists dust and liquid splashes
- Disinfectant-safe design allows frequent sanitization, ideal for healthcare and food industries
🔋 Replaceable Battery Design
- Easy-to-replace battery for extended shift coverage
- Supports multi-shift usage without downtime
💻 Wide Compatibility
- Connects with iOS, Android, and Windows PC/tablets
- Ideal for POS terminals, inventory systems, and mobile devices
Technical Specifications
| Model Name | TH22 Barcode Scanner Wireless 2D |
| Dimension | 208mm x 81mm x 115mm |
| Weight(g) | 460g(Include Base) |
|
Voltage/Current
|
5 VDC +/-10% @ 500 mA
|
| Resolution |
640 pixels (H)x 480 pixels (V)
|
| Battery Capability |
4.2v/2500mAh
|
| Working Horus |
12 hours (1S/Per scan)
|
| Charging Time | 5-6 hours |
| Bluetooth Transmission |
Bluetooth 4.0;
250 meters (open space)
|
| Scanning Type | 1D: UPC, EAN, Code128, Code 39, Code 93, Code11, Matrix 2 of 5, Interleaved 2 of 5,
|
| Scanning Type | 2D: PDF417, MicroPDF417, Data Matrix, Maxicode, QR Code, MicroQR, Aztec, Hanxin,etc.
|
|
Operating Temperature
|
0°C to 50°C
|
|
Storage
|
-40°C to 70°C
|
|
Shock specifications
|
Designed to withstand 1.5m(5’) drops
|
|
Ambient light immunity
|
100.000 Lux
|
🛠️ Applications
- 📦 Warehouse Inventory Management
- 🛒 Retail Checkout & Product Lookup
- 🧾 Postal & Parcel Sorting
- 🚚 Logistics & Distribution
- 🏥 Healthcare Scanning & Patient ID
- 🖨️ OCR Data Capture & Document Validation
❓ Frequently Asked Questions
Q1: How do I connect the scanner to a PC?
A: Simply scan the pairing barcode on the USB dongle—TH22 will auto-connect in seconds.
Q2: What barcode types can it read?
A: TH22 supports all major 1D and 2D codes, postal barcodes, and OCR (optical character recognition) data.
Q3: Is it suitable for healthcare or food handling environments?
A: Yes. The IP42 housing is disinfectant-ready and supports frequent cleaning without damage.
Q4: Can it work with iOS or Android devices?
A: Absolutely. TH22 is compatible with iPhones, iPads, Android tablets and phones, as well as Windows PCs.
Q5: How far can it scan wirelessly?
A: Up to 250 meters in open space using the included dongle—perfect for large, dynamic work areas.
📞 Request Pricing or Distributor Info
Looking for a long-range, easy-to-use wireless scanner for your team?
👉 Contact us today at Info@effon.com for pricing, bulk order options, or OEM branding support.
EFFON – Scanning Smarter, Moving Faster
