TAH2 USB Barcode Scanner – Corded 2D Barcode Reader
Reliable. Fast. Built for All Environments.
Product Overview
The TAH2 USB Barcode Scanner is a high-performance corded 2D handheld barcode reader designed to deliver fast, accurate scanning in a wide range of working conditions.
Equipped with a CMOS 2D scan engine, it can capture barcodes from paper, computer screens, and mobile devices—perfect for retail checkout, e-payment verification, inventory tracking, and more.
Whether you're scanning printed labels or digital codes for mobile payments, the TAH2 QR Scanner USB ensures stable performance, simple connectivity, and broad system compatibility.
⭐ Key Features of Corded Barcode Scanner
🚀 Fast & Precise Scanning
- Equipped with a CMOS 2D scan engine
- 100 scans per second for smooth, efficient data capture
- Supports scanning from paper, screens, and mobile displays
💳 Optimized for Mobile Payments
Instantly reads payment barcodes, electronic coupons, and QR codes from phone screens—ideal for use at POS systems and self-service kiosks.
🔌 Easy Connectivity via USB
Plug-and-play design with USB interface (also supports virtual serial communication). Quick to install and compatible with a wide range of host devices.
🌗 Performs in All Lighting Conditions
Works reliably in low light, direct sunlight, and high-contrast environments. Built to withstand high temperature, humidity, shock, and vibration.
💻 Wide System Compatibility
Fully compatible with Windows, Android, and Linux systems—ideal for diverse commercial, retail, and warehouse platforms.
🔧 Technical Specifications
| Model Name | THA2 Wired Handheld Barcode Scanner |
| Dimension |
110mmL*71mmW*158mmH
|
| Weight(g) | 185g |
| Interface | USB |
| Resolution |
640 X480 CMOS, 30fps
|
|
Reading depth of field
|
EAN13: 40~200mm（13mil） Code128: 45~250mm（20mil） |
| Scanning Type | 1D: EAN13、EAN8、UPC-A、UPC-E0、UPC-E1、
Code128、Code39Code93、CodaBar
Closed 1D barcodes(default): Interleaved2of5、Industrial25、
Matrix2of5、Code11、MSI Plessey、RSS-14、RSS
|
| Scanning Type | 2D: Open 2D barcodes: QRCode、PDF417、DataMatrix（ECC200）
|
|
Working Voltage
|
USB5V
|
|
Working Current
|
125mA
|
|
Communication Port
|
USBHID-KBW（as default)
|
|
Tumble Spec
|
2,000 3.94ft./1.2m tumbles
|
|
Cable length
|
1.8 meters
|
|
Operating Temperature
|
-20°C to 60°C
|
|
Storage
|
-40°C to 60°C
|
🧰 Applications
- Retail checkout counters
- Mobile payment scanning (WeChat, Alipay, QR codes)
- E-ticket and coupon redemption
- Library and school scanning systems
- Warehouse inventory stations
- Self-service terminals
